Triple-Lok® 37° Flare JIC Tube Fittings and Adapters - 6-8 C5OX-S

Parker Triple-Lok 37° Flare JIC Tube Fittings and Adapters are a reliable leak-free metal to metal connection solution for most high pressure hydraulic applications.

Availability:	197 in stock
Partner Available:	2122 in stock

SKU: 6-8 C5OX-S

$13.09

Products specifications

Attribute name	Attribute value
Connection 2 Tube Outside Diameter	na	Connection Type	Tube to SAE-ORB
O-Ring Material	90 Durometer Nitrile	Connection 2 Size	Male SAE-ORB
Connection 2 Thread Size	3/4-16 inch	Connection 3 Tube Outside Diameter	na
Connection 3 Size	na	Shape	90° Elbow
Connection 1 Tube Outside Diameter	3/8 inch	Body Material	Steel
Connection 4 Size	na	Connection 3 Thread Size	na
Maximum Dynamic Pressure	6000 psi	Division	Tube Fittings Division
Dimensional Weight	0.06168277877697842 lb	Connection 4 Tube Outside Diameter	na
Connection 1 Size	Male 37° Flare	Specifications Met	SAE J514
