*PRODUCT IMAGE IS REPRESENTATIVE PROVIDED BY THE MANUFACTURER. DO NOT MAKE BUYING DECISIONS SOLEY BASED ON THE IMAGE. PLEASE VERIFY SPECIFICATIONS MEET YOUR REQUIREMENTS.

Test Port and Diagnostic Quick Couplings (SAE J1502 / ISO 15171-1/Compucheck) - PD Series - PD323

Parker's diagnostic quick couplers and test point nipples provide easy connections for mechanical gauges or specialized diagnostic equipment including Parker's SensoControl meters and accessories.

Availability:	10 in stock
Partner Available:	227 in stock

SKU: PD323

$20.92

Products specifications

Attribute name	Attribute value
Flow Rate	0.8 Gal/min	Maximum Operating Pressure	6000 psi
Dimensional Weight	0.01335431654676259 lb	Seal Material	Nitrile
Plating Type	Zinc with clear trivalent chromate	Division	Quick Coupling Division
Body Size	1/8 inch	Valve Type	Non-spill
Specifications Met	SAE J1502	Maximum Operating Temperature	250 °F
Minimum Operating Temperature	-40 °F	Product Type	Push to Connect
Application	Diagnostics	Body Material	Steel
Hex Size	0.69 inch
Connection Thread Size (inch)	1/8 - 27	Tube Size (inch)	na
Connection Type	Male NPTF	Coupling Half	Male Nipple
