*PRODUCT IMAGE IS REPRESENTATIVE PROVIDED BY THE MANUFACTURER. DO NOT MAKE BUYING DECISIONS SOLEY BASED ON THE IMAGE. PLEASE VERIFY SPECIFICATIONS MEET YOUR REQUIREMENTS.

Test Port and Diagnostic Quick Couplings (SAE J1502 / ISO 15171-1/Compucheck) - PD Series - PD222

Parker's diagnostic quick couplers and test point nipples provide easy connections for mechanical gauges or specialized diagnostic equipment including Parker's SensoControl meters and accessories.

Availability:	Backordered
Partner Available:	55 in stock

SKU: PD222

$60.61

Products specifications

Attribute name	Attribute value
Maximum Operating Temperature	250 °F	Valve Type	Non-spill
Minimum Operating Temperature	-40 °F	Product Type	Push to Connect
Specifications Met	SAE J1502 / ISO 15171-1	Body Material	Steel
Maximum Operating Pressure	6000 psi	Seal Material	Nitrile
Plating Type	Zinc with clear trivalent chromate	Hex Size	0.81 inch
Division	Quick Coupling Division	Application	Diagnostic
Body Size	1/8 inch	Flow Rate	0.8 Gal/min
Tube Size (inch)	na	Coupling Half	Female Coupler
Connection Thread Size (inch)	1/8 - 27	Connection Type	Female NPTF
