Quick Coupling, European profile, ND 5 (Series 21) - 21SLTF10MPX

Name: Quick Coupling, European profile, ND 5 (Series 21) - 21SLTF10MPX
SKU: 21SLTF10MPX
Availability: OutOfStock

Quick coupling system with nominal diameter 5 for pneumatic, liquids and gas applications up to 35 bar. Available in brass, nickel-plated brass, or stainless steel.

Availability:

Backordered

SKU: 21SLTF10MPX

Qty:

Products specifications

Attribute name	Attribute value
Weight	0.025 kg	Division	Low Pressure Connectors Europe Division
Quantity per Box	1	Division	Low Pressure Connectors Europe Division
Body Material	BRASS	Maximum Operating Temperature	100 °C
Minimum Operating Temperature	-20 °C	Seal Material	NBR
Operation Type	n/a	Specifications Met	RoHS
Valve Included	Yes	For Fluid Type	Water
Technology	Fluid & Gas Handling	Industry	General Industrial
Hex Size	14 mm	Region of Origin	Germany
Connection Type	Hose Barb	Application	Trucks & Trailers
Product Style	Quick-Connect	Brand	Rectus
Product Type	Pneumatic Quick Couplings	Connection Size	10 mm
Interchange Type	European Profile	Valve Type	Standard Valve
Plating Type	Without Surface Treatment	Coupling Half	Plug
Diameter	5 mm (nominal)	Product Series	Series 21
Flow Rate	2.7 L/min (water)	Function	Dry-Break (double shut-off)
Maximum Operating Pressure	up to 116 psi
Connection Type	Hose Barb	Materials of Construction	Brass
Connection Size	10 mm	Coupling Half	Plug
Version	Dry-Break (double shut-off)
