Push-to-Connect Nickel Plated Instant Fittings - Prestolok PLP Metal - W68PLP-6-4

Parker's Prestolok PLP push-to-connect fittings offer improved throughput, increased efficiency, smaller footprints, faster assembly and leak-reducing innovation.

Availability:	583 in stock
Partner Available:	4473 in stock

SKU: W68PLP-6-4

$8.72

Products specifications

Attribute name	Attribute value
Vacuum Pressure Rating	28 Inch-Hg	Tube Material	Rigid Nylon
Hex Size	5/8 inch	Brand	Parker
Division	Fluid System Connectors Division	Minimum Operating Temperature	-17.7 °C
Body Material	Brass, Nickel-plated	Region of Origin	United States
Technology	Pneumatics	Dimensional Weight	0.2179 lb
Application	Inert Gases	Specifications Met	UL 94 V-0
Maximum Operating Pressure	20.6 bar	Industry	Semiconductor
Division	Fluid System Connectors Division	For Fluid Type	Oil
Maximum Operating Temperature	93.3 °C	Gripping Ring Material	STAINLESS STEEL
Materials of Construction	PVDF (Button)	Seal Material	Nitrile
Connection 1 Type	Push-to-Connect	Connection 2 Size	1/4"
Connection 2 Type	Male NPTF	Configuration	Tube to Pipe
Product Style	Connector	Connection 1 Size	3/8"
