| Maximum Operating Pressure | 350 bar | Body Material | n/a |
| Division | Hydraulic Cartridge Systems Division | Minimum Operating Temperature | -35 °F |
| Maximum Kinematic Viscosity | 45-2000 SSU (6 to 420 cSt) | Division | Hydraulic Systems Division |
| Maximum Operating Temperature | +200 °F | Flow Rate | 6 Gal/min |
| Override Functionality | n/a | Weight | 0.55 lb |
| Wire Mesh Screen Included | n/a | Maximum Inlet Pressure Rating | 5000 psi |
| Seal Material | D-Ring (Standard) | Actuation Type | Electrical |
| Operation Type | Solenoid Operated | Cavity Size | C08-3L |
| Configuration | Pressure Reducing/Relieving | Installation Torque | 43-49 Nm |
| For Fluid Type | Mineral-based or synthetic hydraulic fluids | Hysteresis | 4% |
| Valve Material | All parts steel. All operating parts hardened steel | Filter Efficiency Rating | ISO 4406 18/16/13, SAE Class 4 |
| Mounting Type | Screw in cartridge valve | Operating Temperature | -37 to +93 °C |
| Maximum Flow Rate | 22.7 L/min | Maximum Tank Pressure | N/A psi |
| Current | 0.73 at 12VDC, 0.365 at 24VDC A | Function | Proportional Pressure Reducing |
| Coil Type | SW7L Standard Short Coil | Frequency | 200-600 Hz |
| Leak Rate | 230 De-Energized cm3/min | Response Time | N/A ms |
| Flow Direction | Inlet port 2, Reducing port 1, Tank port 3 | Power Consumption | 8.4 @ Max Reduced Pressure W |
| Maximum Drain Flow Rate | N/A cm3/min | Maximum Pressure Setting | N/A psi |
| Coil Nut Tightening Torque | 7-9.5 Nm | Maximum Regulating Pressure | 2000 psi |
| Override Functionality | N/A | Maximum Inlet Pressure Rating | 5000 PSI, 350 BAR |
| Seal Material | D-Ring (Standard) | Configuration | Pressure Reducing/Relieving |
| Maximum Flow Rate | 6 GAL/MIN, 22.7 L/MIN | Wire Mesh Screen Included | N/A |
| Maximum Regulating Pressure | 2000 PSI, 138 BAR | | |
