Pneumatic Industrial Interchange Nipples (A-A-59439, MIL-C-4109F, ISO 6150-B) - BH3C

Parker's general purpose, Industrial Interchange quick connect air nipples (plugs) are ideal for use across a spectrum of applications where low pressure air or fluid lines require fast and easy connection and disconnection.

Availability:	268 in stock
Partner Available:	611 in stock

SKU: BH3C

$5.48

Products specifications

Attribute name	Attribute value
Application	Air	Media	Low pressure fluids and compressed air
Plating Type	na	Valve Type	Unvalved
Division	Quick Coupling Division	Specifications Met	A-A-59439 (MIL-C-4109F, ISO 6150-B)
Dimensional Weight	0.006677158273381295 lb	Coupling Half	Nipple
Maximum Operating Pressure	300 psi
Thread Style	Female	Connection Thread Size (inch)	1/4 - 18
Connection Type	NPTF	Connection Hose I.D. (inch)	na
Body Material	BRASS	Body Size (inch)	1/4
