Pipe Fittings and Port Adapters - 10 HP5ON-S

Parker's Pipe Fittings and Port Adapters product line offers a wide range of thread types and high static pressure ratings.

Availability:	76 in stock
Partner Available:	2836 in stock

SKU: 10 HP5ON-S

$3.33

Products specifications

Attribute name	Attribute value
Division	Tube Fittings Division	Connection 4 Size	na
Connection 4 Thread Size	na	Maximum Dynamic Pressure	6000 psi
Fitting Type	Port Adapter	Dimensional Weight	0.020560926258992807 lb
Length (inch)	na	Body Material	Steel
Connection 3 Style	na	Connection 1 Thread Size (mm)	na
Connection 2 Thread Size (mm)	na	Connection 3 Thread Size (inch)	na
Connection 2 Style	na	O-Ring Material	90 Durometer Nitrile
Connection 1 Style	Male SAE-ORB	Connection 1 Thread Size (inch)	7/8-14
Shape	Plug	Connection Style	Hollow Hex Plug
Connection 2 Thread Size (inch)	na
