Ermeto DIN fitting components for high pressure hydraulic tube fittings - M15LCFX

Ermeto DIN fitting components for high pressure hydraulic tube fittings are indispensable items in order to build up a complete fitting series (EO-PSR, EO-2, EO2-FORM).

Availability:	44 in stock
Partner Available:	440 in stock

SKU: M15LCFX

$3.73

Products specifications

Attribute name	Attribute value
Connection 1 Size	15 mm Tube O.D.	Industry	Agriculture
Application	Industrial	Maximum Fluid Temperature	572 °F
Product Style	Components	Minimum Fluid Temperature	-40 °F
Connection 2 Type	Metric	Seal Material	n/a
Technology	Fluid & Gas Handling	Division	High Pressure Connectors Europe Division
Body Material	Steel	Specifications Met	ISO 8434
Maximum Operating Pressure	400 bar	For Fluid Type	Fuels
Shape	n/a	Seal Type	Sealing Edge
Connection 1 Type	Tube	Connection 2 Size	M22x1.5 mm Thread
Minimum Ambient Temperature	-40 °F	Product Series	EO Light
Configuration	Tube to Port	Division	High Pressure Connectors Europe Division
Product Type	Hydraulic DIN Fittings	Maximum Ambient Temperature	572 °F
Brand	Ermeto
Connection 2 Size	M22x1.5	Connection 1 Size	15 mm (O.D.)
Product Style	Nut 24° Cone End	Body Material	Steel
