Coded Quick Coupling especially for fuel gas and oxygen, Series 65-67 - 67KSIL13MVX

Name: Coded Quick Coupling especially for fuel gas and oxygen, Series 65-67 - 67KSIL13MVX
SKU: 67KSIL13MVX
Availability: OutOfStock

Coded quick coupling system with nominal diameter 7.4 especially for use with fuel gas and oxygen up to 35 bar. Available made of ungreased brass.

Availability:

Backordered

SKU: 67KSIL13MVX

Qty:

Products specifications

Attribute name	Attribute value
Division	Low Pressure Connectors Europe Division	Maximum Operating Temperature	100 °C
Flow Rate	800 L/min	Hex Size	19 mm
Valve Included	Yes	Seal Material	FKM
Materials of Construction	Brass ungreased	Minimum Operating Temperature	-20 °C
Version	Single Shut-Off	Diameter	7,4 nom
Maximum Operating Pressure	35 bar	Length	69,5 mm
Outside Diameter	22 mm
Connection Type	Male Thread - parallel - left	Type	Coupling
Connection Thread Size (inch)	1/4	Hose I.D.	na
Application	Var. Media
