Brass Inverted Flare Fittings - 42IFHD-6

Parker's economical inverted flare fittings offer a metal-to-metal seal that is internal to the fitting for tighter tube bends. Meets functional requirements of SAE J512

Availability:	Backordered
Partner Available:	117 in stock

SKU: 42IFHD-6

$6.75

Products specifications

Attribute name	Attribute value
Division	Fluid System Connectors Division	Body Material	BRASS
Maximum Operating Pressure	1000 psi	Maximum Operating Temperature	121 °C
Minimum Operating Temperature	-65 °F	Media	Water, Air, Inert and Non-combustible Gasses, Flammable Liquid, Freon
Tube Material	Copper, Aluminum, brass, Welded Steel Hydraulic tubing that can be flared	Dimensional Weight	0.11037769784172662 lb
Application	Pumps, Brake Lines	Specifications Met	SAE J512
Nut Material	Brass, Zinc Chromate Steel
Connection 2 Thread Size (inch)	na	Connection 2 Tube O.D. (inch)	3/8
Connection 1 Tube O.D. (inch)	3/8	Shape	Union
Style	Flare to Flare	Connection 1 Style	Inverted Flare
Connection 2 Style	Inverted Flare
