Brass Inverted Flare Fittings - 41IFS-8

Parker's economical inverted flare fittings offer a metal-to-metal seal that is internal to the fitting for tighter tube bends. Meets functional requirements of SAE J512

Availability:	Backordered
Partner Available:	2 in stock

SKU: 41IFS-8

Products specifications

Attribute name	Attribute value
Tube Material	Copper, Aluminum, brass, Welded Steel Hydraulic tubing that can be flared	Body Material	BRASS
Division	Fluid System Connectors Division	Nut Material	Brass, Zinc Chromate Steel
Maximum Operating Pressure	52 bar	Minimum Operating Temperature	-53 °C
Application	Pumps, Brake Lines	Media	Water, Air, Inert and Non-combustible Gasses, Flammable Liquid, Freon
Specifications Met	SAE J512	Maximum Operating Temperature	121 °C
Style	Flare	Connection 1 Style	Inverted Flare
Shape	Zinc Nut	Connection 2 Style	na
Connection 2 Thread Size (inch)	na	Connection 1 Tube O.D. (inch)	1/2
Connection 2 Tube O.D. (inch)	na
