Triple-Lok® 37° Flare JIC Tube Fittings and Adapters - 8 C5OX-S

Parker Triple-Lok 37° Flare JIC Tube Fittings and Adapters are a reliable leak-free metal to metal connection solution for most high pressure hydraulic applications.

Availability:	328 in stock
Partner Available:	5232 in stock

SKU: 8 C5OX-S

$14.08

Products specifications

Attribute name	Attribute value
Connection 3 Tube Outside Diameter	na	Dimensional Weight	0.03871402877697842 lb
Shape	90° Elbow	Body Material	Steel
Connection 4 Size	na	Connection 3 Thread Size	na
Maximum Dynamic Pressure	6000 psi	Connection 1 Tube Outside Diameter	1/2 inch
Division	Tube Fittings Division	Connection 1 Size	Male 37° Flare
Connection 4 Tube Outside Diameter	na	Connection Type	37° Flare
Specifications Met	SAE J514	Connection 2 Tube Outside Diameter	na
Connection 2 Thread Size	3/4-16 inch	O-Ring Material	90 Durometer Nitrile
Connection 2 Size	Male SAE-ORB	Connection 3 Size	na
