Triple-Lok® 37° Flare JIC Tube Fittings and Adapters - 8-8 WGTX-WLN-SS

Parker Triple-Lok 37° Flare JIC Tube Fittings and Adapters are a reliable leak-free metal to metal connection solution for most high pressure hydraulic applications.

Availability:	Backordered
Partner Available:	Backordered

SKU: 8-8 WGTX-WLN-SS

$265.80

Products specifications

Attribute name	Attribute value
Connection 1 Tube Outside Diameter	12 mm	Connection 2 Tube Outside Diameter	na
Connection 2 Thread Size	1/2-14 inch	Connection Type	Bulkhead Tube to NPT
Dimensional Weight	0.12464028776978417 lb	Body Material	Stainless Steel
Shape	Straight	Connection 3 Size	na
Connection 3 Tube Outside Diameter	na	Maximum Dynamic Pressure	5000 psi
Division	Tube Fittings Division	Connection 4 Size	na
Connection 3 Thread Size	na	Connection 4 Tube Outside Diameter	na
Connection 1 Size	Male 37° Flare Bulkhead with Locknut	Specifications Met	SAE J514
Connection 2 Size	Female NPT/NPTF	O-Ring Material	na
