Triple-Lok® 37° Flare JIC Tube Fittings and Adapters - 8-8 FTX-S

Parker Triple-Lok 37° Flare JIC Tube Fittings and Adapters are a reliable leak-free metal to metal connection solution for most high pressure hydraulic applications.

Availability:	639 in stock
Partner Available:	3993 in stock

SKU: 8-8 FTX-S

$4.78

Products specifications

Attribute name	Attribute value
Shape	Straight	Division	Tube Fittings Division
Connection 3 Thread Size	na	Connection 2 Size	Male NPT/NPTF
Body Material	Steel	Connection 4 Size	na
Maximum Dynamic Pressure	6000 psi	Connection Type	37° Flare
Connection 4 Tube Outside Diameter	na	Connection 1 Size	Male 37° Flare
Dimensional Weight	0.03855173673561151 lb	Specifications Met	SAE J514
O-Ring Material	na	Connection 2 Tube Outside Diameter	na
Connection 1 Tube Outside Diameter	12 mm	Connection 2 Thread Size	1/2-14 inch
Connection 3 Tube Outside Diameter	na	Connection 3 Size	na
