Test Port and Diagnostic Quick Couplings (SAE J1502 / ISO 15171-1/Compucheck) - PD Series - PD341

Parker's diagnostic quick couplers and test point nipples provide easy connections for mechanical gauges or specialized diagnostic equipment including Parker's SensoControl meters and accessories.

Availability:	49 in stock
Partner Available:	1420 in stock

SKU: PD341

$22.54

Products specifications

Attribute name	Attribute value
Application	Diagnostics	Product Type	Push to Connect
Hex Size	0.69 inch	Body Material	Steel
Dimensional Weight	0.009997002398081534 lb	Maximum Operating Pressure	6000 psi
Seal Material	Nitrile	Plating Type	Zinc with clear trivalent chromate
Flow Rate	0.8 Gal/min	Division	Quick Coupling Division
Body Size	1/8 inch	Specifications Met	SAE J1502
Valve Type	Non-spill	Maximum Operating Temperature	250 °F
Minimum Operating Temperature	-40 °F
Coupling Half	Male Nipple	Connection Type	Male UNF
Tube Size (inch)	na	Connection Thread Size (inch)	7/16 - 20
