Seal-Lok O-Ring Face Seal Tube Fittings and Adapters - 10-6 F5OLO-S

Parker's Seal-Lok O-Ring Face Seal fitting design provides leak-free connections in applications with high-pressure, vibration and impulse environments. Using the new FastSeal nut, ORFS tube connections can be made in minutes without flanging or brazing.

Availability:	Backordered
Partner Available:	36 in stock

SKU: 10-6 F5OLO-S

$14.20

Products specifications

Attribute name	Attribute value
Division	Tube Fittings Division	Dimensional Weight	0.07913669064748201 lb
Maximum Dynamic Pressure	6000 psi	Body Material	Steel
Shape	Straight	O-Ring Material	90 Durometer Nitrile
Specifications Met	SAE J1453	Connection Type	Tube to SAE Straight Thread
Connection 1 Type	Male O-Ring Face Seal	Connection 2 Type	Male SAE-ORB
Connection 3 Type	na	Connection 4 Type	na
Connection 3 Thread Size	na	Connection 1 Tube Outside Diameter	5/8 inch
Connection 2 Tube Outside Diameter	na	Connection 3 Tube Outside Diameter	na
Connection 4 Tube Outside Diameter	na	Connection 2 Thread Size	9/16-18 inch
