Quick Coupling with Parker own Profile, Series 38 - 38KFIW26MPX

Name: Quick Coupling with Parker own Profile, Series 38 - 38KFIW26MPX
SKU: 38KFIW26MPX
Availability: OutOfStock

Quick coupling system with nominal diameter 15 for pneumatic and fluid handling applications up to 35 bar. Coupling system with Parker own profile. Available made of brass.

Availability:

Backordered

SKU: 38KFIW26MPX

Qty:

Products specifications

Attribute name	Attribute value
Outside Diameter	40	Maximum Operating Temperature	100
Valve Included	Yes	Length	91
Minimum Operating Temperature	-20	Hex Size	34
Diameter	15	Division	Low Pressure Connectors Europe Division
Flow Rate	n/a	Maximum Operating Pressure	35
Seal Material	NBR
Hose I.D.	n/a	Connection Type	Female Thread - parallel
Material	Brass	Version	Straight Through
Type	Coupling	Connection Thread Size (inch)	3/4
