Quick Coupling with Parker own Profile, Series 38 - 38KBIW26MVX

Name: Quick Coupling with Parker own Profile, Series 38 - 38KBIW26MVX
SKU: 38KBIW26MVX
Availability: OutOfStock

Quick coupling system with nominal diameter 15 for pneumatic and fluid handling applications up to 35 bar. Coupling system with Parker own profile. Available made of brass.

Availability:

Backordered

SKU: 38KBIW26MVX

Qty:

Products specifications

Attribute name	Attribute value
Minimum Operating Temperature	-15 °C	Division	Low Pressure Connectors Europe Division
Length	91 mm	Hex Size	34 mm
Flow Rate	27 L/min (Water)	Seal Material	FKM
Valve Included	Yes	Outside Diameter	40 mm
Maximum Operating Temperature	200 °C	Diameter	15 nom
Maximum Operating Pressure	35 bar
Connection Thread Size (inch)	3/4	Hose I.D.	na
Type	Coupling	Material	Brass
Version	Double Shut-Off	Connection Type	Female Thread - parallel
