Quick Coupling with ISO 6150 C Profile for Railway Applications, Series 303 - 303SFIW13MXN

Name: Quick Coupling with ISO 6150 C Profile for Railway Applications, Series 303 - 303SFIW13MXN
SKU: 303SFIW13MXN
Availability: OutOfStock

Quick coupling system with nominal diameter 3 for railway applications up to 35 bar. Coupling system with ISO 6150 C profile. Available made of brass or stainless steel.

Availability:

Backordered

SKU: 303SFIW13MXN

Qty:

Products specifications

Attribute name	Attribute value
Division	Low Pressure Connectors Europe Division	Maximum Operating Temperature	100 °C
Maximum Operating Pressure	35 bar	Version	Single Shut-Off
Valve Included	No	Hex Size	17 mm
Application	Railway	Length	33 mm
Outside Diameter	na	Minimum Operating Temperature	-55 °C
Profile	ISO C	Diameter	3 nom
Seal Material	Cryogenic NBR
Type	Plug	Material	Brass
Hose I.D.	na	Connection Thread Size (inch)	1/4
Connection Type	Female Thread

Product resources

Compliance, Certifications & Safety

Certificate of conformity - 2014 68 EU_connectic
