*PRODUCT IMAGE IS REPRESENTATIVE PROVIDED BY THE MANUFACTURER. DO NOT MAKE BUYING DECISIONS SOLEY BASED ON THE IMAGE. PLEASE VERIFY SPECIFICATIONS MEET YOUR REQUIREMENTS.

Quick Coupling with ARO Profile, Series 14 - 14KAAW21MPN

Name: Quick Coupling with ARO Profile, Series 14 - 14KAAW21MPN
SKU: 14KAAW21MPN
Availability: OutOfStock

Quick coupling system with nominal diameter 5.5 for pneumatic and fluid handling applications up to 35 bar. Coupling system with ARO profile which is most common in Benelux countries, Switzerland as well as in South Africa. Available made of brass/steel.

Availability:

Backordered

SKU: 14KAAW21MPN

Qty:

Products specifications

Attribute name	Attribute value
Division	Low Pressure Connectors Europe Division	Maximum Operating Temperature	100 °C
Minimum Operating Temperature	-20 °C	Seal Material	NBR
Maximum Operating Pressure	35 bar	Version	Single Shut-Off
Valve Included	Yes	Length	46 mm
Diameter	5,5 nom	Hex Size	22 mm
Outside Diameter	25 mm	Flow Rate	560 L/min
Type	Coupling	Material	Brass nickel plated
Connection Type	Male Thread - parallel	Connection Thread Size (inch)	1/2
Hose I.D. (mm)	na
