Push-to-Connect Nickel Plated Instant Fittings - Prestolok PLP Metal - W169PLP-6-2

Parker's Prestolok PLP push-to-connect fittings offer improved throughput, increased efficiency, smaller footprints, faster assembly and leak-reducing innovation.

Availability:	35 in stock
Partner Available:	1075 in stock

SKU: W169PLP-6-2

$9.76

Products specifications

Attribute name	Attribute value
Division	Fluid System Connectors Division	Brand	Parker
Seal Material	Nitrile	Vacuum Pressure Rating	28 Inch-Hg
Industry	Industrial Manufacturing Equipment	For Fluid Type	Air
Hex Size	9/16 inch	Technology	Pneumatics
Gripping Ring Material	STAINLESS STEEL	Body Material	Brass, Nickel-plated
Maximum Operating Pressure	300 psi	Application	Inert Gases
Specifications Met	UL 94 V-0	Materials of Construction	PVDF (Button)
Division	Fluid System Connectors Division	Tube Material	Nylon
Region of Origin	United States	Maximum Operating Temperature	93.3 °C
Minimum Operating Temperature	-17.7 °C	Dimensional Weight	0.2179 lb
Connection 2 Size	1/8"	Connection 1 Size	3/8"
Connection 1 Type	Push-to-Connect	Configuration	Tube to Pipe
Connection 2 Type	Male NPTF	Shape	Elbow 90° - Swivel
