| Maximum Operating Pressure | 210 bar | Seal Material | Fluorocarbon |
| Body Material | n/a | Division | Hydraulic Cartridge Systems Division |
| Minimum Operating Temperature | -26 °C | Maximum Kinematic Viscosity | 45-2000 SSU (6 to 420 cSt) |
| Division | Hydraulic Systems Division | Weight | 0.13 kg |
| Maximum Flow Rate | 30 L/min | Flow Rate | 30 L/min |
| Installation Torque | 30 Nm | Coil Nut Tightening Torque | 3 lb-ft |
| Coil Type | 5/8" Super Coil High Watt (CAP) | Power Consumption | 28 W |
| Response Time | 40 ms | For Fluid Type | Mineral-based or synthetic hydraulic fluids |
| Maximum Operating Temperature | +400 °F | Frequency | 100-400 Hz |
| Actuation Type | Electrical, Manual | Operation Type | Solenoid operated, Manually operated |
| Valve Material | All parts steel. All operating parts hardened steel | Operating Temperature | -15 to +400 °F |
| Filter Efficiency Rating | ISO 4406 18/16/13, SAE Class 4 | Maximum Inlet Pressure Rating | 210 bar |
| Mounting Type | Screw in cartridge valve | Wire Mesh Screen Included | Yes |
| Maximum Tank Pressure | N/A psi | Function | Proportional Pressure Reducing |
| Maximum Pressure Setting | N/A psi | Cavity Size | 3X |
| Leak Rate | N/A cm3/min | Current | 1.4 at 12VDC (High watt), 0.7 at 24VDC (High watt) A |
| Hysteresis | 3.5% | Configuration | Side Cylinder Port |
| Flow Direction | Inlet port 3, Reducing port 2, Tank port 1 | Override Functionality | Infinite Control |
| Maximum Drain Flow Rate | 25 De-Energized, 800 In Regulating Zone @ 300 PSI (21 BAR) cm3/min | Maximum Regulating Pressure | 420-550 psi |
| Seal Material | Fluorocarbon | Maximum Inlet Pressure Rating | 3000 PSI, 210 BAR |
| Maximum Flow Rate | 8 GAL/MIN, 30 L/MIN | Wire Mesh Screen Included | Yes |
| Configuration | Side Cylinder Port | Override Functionality | Infinite Control |
| Maximum Regulating Pressure | 420-550 PSI, 29-38 BAR | | |
