| Weight | 0.08 kg | Maximum Operating Pressure | 3000 psi |
| Seal Material | Fluorocarbon | Body Material | n/a |
| Division | Hydraulic Cartridge Systems Division | Minimum Operating Temperature | -26 °C |
| Maximum Kinematic Viscosity | 45-2000 SSU (6 to 420 cSt) | Division | Hydraulic Systems Division |
| Power Consumption | 19 W | Maximum Flow Rate | 5 Gal/min |
| Flow Rate | 19 L/min | Maximum Inlet Pressure Rating | 3000 psi |
| Coil Type | 1/2" Super Coil High Watt (CCP) | Coil Nut Tightening Torque | 3 lb-ft |
| Cavity Size | C08-3 | Response Time | 10 ms |
| For Fluid Type | Mineral-based or synthetic hydraulic fluids | Maximum Operating Temperature | +400 °F |
| Frequency | 100-400 Hz | Actuation Type | Electrical, Manual |
| Operation Type | Solenoid operated, Manually operated | Valve Material | All parts steel. All operating parts hardened steel |
| Operating Temperature | -26 to +204 °C | Filter Efficiency Rating | ISO 4406 18/16/13, SAE Class 4 |
| Mounting Type | Screw in cartridge valve | Wire Mesh Screen Included | Yes |
| Maximum Tank Pressure | N/A psi | Function | Proportional Pressure Reducing |
| Maximum Pressure Setting | N/A psi | Installation Torque | 20 lb-ft |
| Leak Rate | N/A cm3/min | Current | 1.4 at 12VDC (High watt), 0.7 at 24VDC (High watt) A |
| Hysteresis | 3.5% | Configuration | Side Cylinder Port |
| Flow Direction | Inlet port 3, Reducing port 2, Tank port 1 | Override Functionality | Infinite Control |
| Maximum Drain Flow Rate | 100 De-Energized, 750 In Regulating Zone @ 300 PSI (21 BAR) cm3/min | Maximum Regulating Pressure | 31-40 bar |
| Seal Material | Fluorocarbon | Maximum Inlet Pressure Rating | 3000 PSI, 210 BAR |
| Maximum Flow Rate | 5 GAL/MIN, 19 L/MIN | Wire Mesh Screen Included | Yes |
| Configuration | Side Cylinder Port | Override Functionality | Infinite Control |
| Maximum Regulating Pressure | 450-580 PSI, 31-40 BAR | | |
