| Weight | 0.08 kg | Maximum Operating Pressure | 210 bar |
| Seal Material | Nitrile | Body Material | n/a |
| Division | Hydraulic Cartridge Systems Division | Maximum Kinematic Viscosity | 45-2000 SSU (6 to 420 cSt) |
| Division | Hydraulic Systems Division | Minimum Operating Temperature | -30 °F |
| Override Functionality | n/a | Maximum Inlet Pressure Rating | 3000 psi |
| Actuation Type | Electrical | Operation Type | Solenoid Operated |
| For Fluid Type | Mineral-based or synthetic hydraulic fluids | Maximum Operating Temperature | +250 °F |
| Frequency | 100-400 Hz | Valve Material | All parts steel. All operating parts hardened steel |
| Operating Temperature | -30 to +250 °F | Filter Efficiency Rating | ISO 4406 18/16/13, SAE Class 4 |
| Mounting Type | Screw in cartridge valve | Wire Mesh Screen Included | Yes |
| Function | Proportional Pressure Reducing | Flow Direction | Inlet port 2, Reducing port 1, Tank port 3 |
| Maximum Pressure Setting | N/A psi | Coil Nut Tightening Torque | Finger Tight Nm |
| Installation Torque | 27 Nm | Current | 1.1 at 12VDC (Low watt), 1.4 at 12VDC (High watt), 0.6 at 24VDC (Low watt), 0.7 at 24VDC (High watt) A |
| Coil Type | 1/2" Super Coil High Watt (CCP), 1/2" Super Coil Low Watt (CCS) | Flow Rate | 0.5 Gal/min |
| Leak Rate | N/A cm3/min | Hysteresis | 2% |
| Cavity Size | 54-1 | Configuration | Bottom Cylinder Port |
| Response Time | 10 (Off), 30 (On) ms | Maximum Flow Rate | 1.9 L/min |
| Power Consumption | 14, 19 W | Maximum Tank Pressure | 440 psi |
| Maximum Drain Flow Rate | 5 De-Energized, 200 In Regulating Zone @ 1000 PSI (68 BAR) cm3/min | Maximum Regulating Pressure | 17 (Low Watt), 22 (High Watt) bar |
| Override Functionality | N/A | Seal Material | Nitrile |
| Maximum Inlet Pressure Rating | 3000 PSI, 210 BAR | Wire Mesh Screen Included | Yes |
| Configuration | Bottom Cylinder Port | Maximum Flow Rate | 0.5 GAL/MIN, 1.9 L/MIN |
| Maximum Regulating Pressure | 250 PSI, 17 BAR Standard, or 320 PSI, 22 BAR High Pressure | | |
