Premium Quick Coupling with ARO Profile, Series 22 - 22SFTF09MXN

Name: Premium Quick Coupling with ARO Profile, Series 22 - 22SFTF09MXN
SKU: 22SFTF09MXN
Availability: OutOfStock

Premium quick coupling system with nominal diameter 5.5 for pneumatic and fluid handling applications up to 35 bar. Coupling system with ARO profile. Available made of brass/steel.

Availability:

Backordered

SKU: 22SFTF09MXN

Qty:

Products specifications

Attribute name	Attribute value
Division	Low Pressure Connectors Europe Division	Maximum Operating Temperature	100 °C
Minimum Operating Temperature	-20 °C	Seal Material	na
Maximum Operating Pressure	35 bar	Version	Single Shut-Off
Hex Size	na	Valve Included	No
Outside Diameter	12 mm	Flow Rate	800 L/min
Length	48,5 mm
Type	Plug	Connection Type	Hose Barb
Connection Thread Size (inch)	na	Hose I.D.	9
Material	Brass nickel plated
