Premium Plus Quick Coupling - Scandinavian Profile - Series 2100 - 2100SFTF19SXZ

Name: Premium Plus Quick Coupling - Scandinavian Profile - Series 2100 - 2100SFTF19SXZ
SKU: 2100SFTF19SXZ
Availability: OutOfStock

Brass or steel Premium plus quick coupling system with nominal diameter 22 and Scandinavian profile for applications up to 20 bar.

Availability:

Backordered

SKU: 2100SFTF19SXZ

Qty:

Products specifications

Attribute name	Attribute value
Maximum Operating Temperature	100 °C	Minimum Operating Temperature	-20 °C
Maximum Operating Pressure	20 bar	Materials of Construction	Steel
Seal Material	na	Version	Single Shut-Off
Hex Size	na	Valve Included	No
Division	High Pressure Connectors Europe Division	Diameter	22 nom
Outside Diameter	na	Length	74 mm
Flow Rate	12000 L/min
Type	Plug	Connection Type	Hose Barb
Connection Thread Size (inch)	na	Hose I.D.	19
