Nylon Tubing - N-4-040-RED-0100

Name: Nylon Tubing - N-4-040-RED-0100
SKU: N-4-040-RED-0100
Availability: OutOfStock

Nylon plastic tubing tubing is formulated from abrasion-resistant, heat and light-stabilized nylon that is capable of operating at 200°F. It exhibits low-level water absorption and is chemically resistant. (Series N/NB)

Availability:

Backordered

SKU: N-4-040-RED-0100

Qty:

Products specifications

Attribute name	Attribute value
Specifications Met	N/A	Maximum Operating Temperature	93 °C
Minimum Operating Temperature	-65 °F	Size	-4
Length per Package	30.5 m Box	Media	Lubricants
Color	Red	Division	Parflex Division
Tube Outside Diameter	6.4 mm	Weight	0.018 kg/m
Tube Material	Polyamide (PA)	Tube Inside Diameter	4.3 mm
Minimum Burst Pressure	86.2 bar	Application	Fluid Transfer
Maximum Operating Pressure	310 psi	Compatible Fitting	Flow Controls
Cover Material	n/a	Minimum Bend Radius	0.88 inch
Standard Pack Qty (ft)	100 ft box	Order Size	1/4
Color	RED
