*PRODUCT IMAGE IS REPRESENTATIVE PROVIDED BY THE MANUFACTURER. DO NOT MAKE BUYING DECISIONS SOLEY BASED ON THE IMAGE. PLEASE VERIFY SPECIFICATIONS MEET YOUR REQUIREMENTS.

Non-Spill, Flat Face, Push to Connect Quick Couplings with Sleeve Lock - NS Series - NS-1002-16FO

Parker's non-spill, flat face hydraulic couplers are ideal for use across a variety of hydraulic applications where fluid lines require fast and easy connection and disconnection with minimal spillage and limited air inclusion.

Availability:	Backordered
Partner Available:	Backordered

SKU: NS-1002-16FO

$213.77

Products specifications

Attribute name	Attribute value
Seal Material	Nitrile	Hex Size	1.62 inch
Body Material	Steel	Product Type	Push to Connect
Minimum Operating Temperature	-40 °F	Maximum Operating Temperature	250 °F
Maximum Operating Pressure	2500 psi	Valve Type	Non-spill
Division	Quick Coupling Division	Flow Rate	50 Gal/min
Plating Type	Zinc with clear trivalent chromate	Application	Hydraulic
Coupling Half	Male Nipple	Connection Thread Size (inch)	1 5/16 - 12
Body Size (inch)	1	Connection Type	Female ORB

Product resources

Literature and Reference Materials

Compliance, Certifications & Safety

Safety Guide: Quick Couplings and Related Accessories
