Multi-Station Manifolds - Series MSP - MSP1D23BA910

Name: Multi-Station Manifolds - Series MSP - MSP1D23BA910
SKU: MSP1D23BA910
Availability: OutOfStock

Multi-station manifolds series MSP are used to save space when connecting several directional control valves to a common pressure and return line.

Availability:

Backordered

SKU: MSP1D23BA910

Qty:

Products specifications

Attribute name	Attribute value
Maximum Flow Rate	n/a	Surface Finish	Phosphated (no permanent corrosion protection)
Maximum Operating Pressure	350 bar	Product Series	Manifold
Function	n/a	Mounting Type	Subplate mounting
Connection Type	BSPP port thread	Division	Industrial Systems Division Europe
Mounting Position	Unrestricted (valve axis preferably horizontal)	Weight	2.1 kg
Minimum Operating Temperature	-25 °C	Actuation Type	n/a
Maximum Operating Temperature	70 °C	For Fluid Type	Hydraulic oil, Water glycol
Seal Material	n/a	Body Material	Steel
Product Style	1 Station	Port Connection	NG06 / CETOP 03
Gauge Port Connection	N/A	Port Size	A, B = G 3/8 / P,T = G 1/2
Port Location	Port A+B side
