Isys ISO H1 Series Double Solenoid 4-way 2-position Valve - H12VXXG023D

Isys ISO H1 Series Double Solenoid 4-way 2-position Valve

Availability:	Backordered
Partner Available:	Backordered

SKU: H12VXXG023D

$197.30

Products specifications

Attribute name	Attribute value
Override Type	Non-locking	CV Factor	1.5
Pilot Supply	External	UOM	EA
Operator Type Detail	Double	Pkg Qty	1
Solenoid Voltage	120 VAC
CV Factor	1.5	Override Type	Non-locking
Parker Division	Pneumatic	Valve Passages	4-way
Parker Group	Automation	Series Type	H1
Valve Positions	2-position	Trade Name	Isys
Series	Isys	Operator Type Detail	Double
Pilot Supply	External	Pneumatic Valve Type	Plug-in Valve
Solenoid Voltage	120 VAC	Operator Type	Solenoid
ISO Interface	ISO 5599-2, Plug-in, Size 1 (H1)
