Industrial & European Interchange, Quick Connect Air Couplers - Tool-Mate Standard Series - PER-251-6FP

Parker's non-marking, lightweight, pneumatic, air quick connect couplers are ideal for use across a spectrum of applications where low pressure air lines require fast and easy connection and disconnection.

Availability:	Backordered
Partner Available:	Backordered

SKU: PER-251-6FP

$45.87

Products specifications

Attribute name	Attribute value
Body Material	Polyamide	Seal Material	Nitrile
Dimensional Weight	0.12464028776978417 lb	Maximum Operating Pressure	300 psi
Media	Compressed Air	Valve Type	Tubular
Coupling Half	Coupler	Lock Type	Polyacetate Locking Fingers
Division	Quick Coupling Division	Specifications Met	Connects with RF style nipples
Plating Type	Galvanized Steel Port Ends	Sleeve Type	Push-to-Connect
Minimum Operating Temperature	0 °F	Maximum Operating Temperature	160 °F
Application	Air
Interface Option	Connects with RF style nipples	Connection Type	Female, NPTF
Body Size	1/4"	Connection Thread Size	3/8"-18
Thread Style	Female

Product resources

Compliance, Certifications & Safety

Safety Guide: Quick Couplings and Related Accessories

Literature and Reference Materials
