*PRODUCT IMAGE IS REPRESENTATIVE PROVIDED BY THE MANUFACTURER. DO NOT MAKE BUYING DECISIONS SOLEY BASED ON THE IMAGE. PLEASE VERIFY SPECIFICATIONS MEET YOUR REQUIREMENTS.

Inch Brass Compression Fittings - 60PT-10

Parker's compression fittings require no flaring, soldering or other preparation of tubing necessary to assemble. Offered in both forgings and extrusions compression fittings meet functional requirements of SAE J-512

Availability:	Backordered
Partner Available:	117 in stock

SKU: 60PT-10

$1.06

Products specifications

Attribute name	Attribute value
Weight	na	Media	Water, air, inert and non-combustible gasses
Maximum Operating Temperature	121 °C	Nut Material	BRASS
Sleeve Material	Brass, Acetal	Quantity per Box	na
Application	Compressors, Machine Tools, Engine, Pumps, Purification	Minimum Operating Temperature	-65 °F
Tube Material	Copper, Aluminum, Thermoplastic	Specifications Met	SAE J-512
Maximum Operating Pressure	650 psi	Division	Fluid System Connectors Division
Body Material	Acetal	Product Style	Sleeve
Connection 1 Type	Compression	Connection 1 Size	5/8"
