Hydraulic Quick Coupling with Parker Profile - Series H - H5010 V

Name: Hydraulic Quick Coupling with Parker Profile - Series H - H5010 V
SKU: H5010 V
Availability: OutOfStock

Quick coupling system with body sizes 1/2" up to 1" and Parker Profile for medium pressure applications up to 320 bar.

Availability:

Backordered

SKU: H5010 V

Qty:

Products specifications

Attribute name	Attribute value
Operating Pressure	320 bar	Minimum Operating Temperature	-25 °C
Connection Thread Size	1/2 inch	Hex Size	30 mm
Division	High Pressure Connectors Europe Division	Materials of Construction	Brass / Steel
Maximum Operating Temperature	200 °C	Outside Diameter	40 mm
Connection Type	Female Thread	Length	65 mm
Type	Coupling	Body Size (inch)	1/2
Version	Standard	Seal Material	FKM

Product resources

Compliance, Certifications & Safety

Safety instructions Quick Couplings

Literature and Reference Materials

Hydraulic Quick Couplings Catalogue--CAT/3800-HYD/UK
Catalog 3800 Quick Coupling Products
