Hydraulic Constant Working Pressure Hose 3000 PSI - GlobalCore 387 Hose - 387TC-4

Part of Parker’s GlobalCore constant working pressure hose line, lightweight and flexible 387 hoses consistently deliver 3,000 PSI performance across markets and across the globe.

Availability:	13649 in stock
Partner Available:	20254 in stock

SKU: 387TC-4

$5.07

Products specifications

Attribute name	Attribute value
Minimum Operating Temperature	-40 °F	Division	Hose Products Division
Disclaimer	The user, through its own analysis and testing, is solely responsible for making the final selection of the system and components and assuring that all performance, endurance, maintenance, safety and warning requirements of the application are met.	Maximum Operating Temperature	125 °C
Maximum Operating Pressure	3000 psi	Size	-4
Inside Diameter	1/4 inch	Minimum Bend Radius	2 inch
Application	Lubricating Oils	Media	Lubricants
Cover Material	Synthetic Rubber Abrasion Resistant	Hose Cover Type	Tough Cover
Compatible Fitting	43 Series	Hose Inner Tube Material	Synthetic Rubber
Hose Reinforcement Material	1 Braid of Steel Wire	Nominal Hose Inside Diameter	6 mm
Weight	0.24 kg/m	Outside Diameter	13.4 mm
Specifications Met	ISO 18752, Type AC
Hose I.D. (size)	-4	Hose Cover Type	ToughCover
