High Pressure, Thread to Connect Couplings, API 16D - 75 Series - S75N48-48F

Name: High Pressure, Thread to Connect Couplings, API 16D - 75 Series - S75N48-48F
SKU: S75N48-48F
Availability: OutOfStock

Parker's heavy duty thread to connect quick couplers and nipples are used in rugged hydraulic applications where fluid lines require connection and disconnection while either the coupler or nipple are under residual pressure.

Availability:

Backordered

SKU: S75N48-48F

Qty:

Products specifications

Attribute name	Attribute value
Minimum Operating Temperature	-40 °F	Division	Quick Coupling Division
Plating Type	na	Seal Material	Nitrile
Hex Size	4.25 inch	Product Type	Thread-to-Connect
Body Material	Stainless Steel	Maximum Operating Temperature	250 °F
Valve Type	Poppet	Application	Hydraulic high pressure, connect under pressure
Body Size (inch)	3	Connection Type	Female NPTF
Connection Thread Size (inch)	3 - 8	Maximum Operating Pressure	3000
Coupling Half	Male Nipple	Sleeve Type	na
Specifications Met	na

Product resources

Compliance, Certifications & Safety

Safety Guide: Quick Couplings and Related Accessories

Literature and Reference Materials
