High Pressure, Hydraulic General Purpose Quick Couplings - SM Series - SM-252-6FP

Parker's general purpose quick couplers and nipples are ideal for use in hydraulic applications where fluid lines require fast and easy connection and disconnection.

Availability:	1 in stock
Partner Available:	189 in stock

SKU: SM-252-6FP

$22.00

Products specifications

Attribute name	Attribute value
Seal Material	Nitrile	Body Material	Steel
Hex Size	0.94	Maximum Operating Temperature	250 °F
Minimum Operating Temperature	-40 °F	Product Type	Manual Connect
Valve Type	Poppet	Application	Hydraulics
Dimensional Weight	0.02670863309352518 lb	Plating Type	Zinc with clear trivalent chromate
Division	Quick Coupling Division
Flow Rate	3 GAL/MIN	Body Size (inch)	1/4
Connection Type	Female NPTF	Maximum Operating Pressure	6000 PSI
Coupling Half	Male Nipple	Connection Thread Size (inch)	3/8 - 18
