High Pressure, Hydraulic General Purpose Quick Couplings - SM Series - SM-251-6FP

Parker's general purpose quick couplers and nipples are ideal for use in hydraulic applications where fluid lines require fast and easy connection and disconnection.

Availability:	15 in stock
Partner Available:	65 in stock

SKU: SM-251-6FP

$40.37

Products specifications

Attribute name	Attribute value
Division	Quick Coupling Division	Seal Material	Nitrile
Body Material	Steel	Hex Size	0.94
Maximum Operating Temperature	250 °F	Minimum Operating Temperature	-40 °F
Valve Type	Poppet	Product Type	Manual Connect
Application	Hydraulics	Dimensional Weight	0.05341726618705036 lb
Plating Type	Zinc with clear trivalent chromate
Flow Rate	3 GAL/MIN	Coupling Half	Female Coupler
Connection Type	Female NPTF	Body Size (inch)	1/4
Maximum Operating Pressure	6000 PSI	Connection Thread Size (inch)	3/8 - 18

Product resources

Compliance, Certifications & Safety

Safety Guide: Quick Couplings and Related Accessories

Literature and Reference Materials
