High Flow, Unvalved, Hydraulic Quick Couplings - ST Series - SST-N8M

Parker's high flow quick couplers and nipples are unvalved for use where fluid lines require fast and easy connection and disconnection while providing maximum flow and low pressure drop.

Availability:	Backordered
Partner Available:	18 in stock

SKU: SST-N8M

$124.16

Products specifications

Attribute name	Attribute value
Dimensional Weight	0.12464028776978417 lb	Product Type	Push to Connect
Seal Material	n/a	Hex Size	1.38 inch
Maximum Operating Temperature	250 °F	Minimum Operating Temperature	-40 °F
Valve Type	Unvalved	Application	Hydraulics
Flow Rate	50 Gal/min	Plating Type	n/a
Division	Quick Coupling Division
Connection Thread Size (inch)	1 - 11 1/2	Body Size (inch)	1
Coupling Half	Male Nipple	Body Material	303 Stainless Steel
Connection Type	Male NPTF	Maximum Operating Pressure	1700

Product resources

Literature and Reference Materials

Compliance, Certifications & Safety

Safety Guide: Quick Couplings and Related Accessories
