High Flow, Unvalved, Hydraulic Quick Couplings - ST Series - SST-N8

Parker's high flow quick couplers and nipples are unvalved for use where fluid lines require fast and easy connection and disconnection while providing maximum flow and low pressure drop.

Availability:	Backordered
Partner Available:	11 in stock

SKU: SST-N8

$128.68

Products specifications

Attribute name	Attribute value
Product Type	Push to Connect	Seal Material	n/a
Hex Size	1.63 inch	Maximum Operating Temperature	250 °F
Application	Hydraulics	Minimum Operating Temperature	-40 °F
Valve Type	Unvalved	Plating Type	n/a
Flow Rate	50 Gal/min	Division	Quick Coupling Division
Dimensional Weight	0.12464028776978417 lb
Connection Type	Female NPTF	Body Size (inch)	1
Coupling Half	Male Nipple	Body Material	303 Stainless Steel
Maximum Operating Pressure	1700	Connection Thread Size (inch)	1 - 11 1/2

Product resources

Literature and Reference Materials

Compliance, Certifications & Safety

Safety Guide: Quick Couplings and Related Accessories
