*PRODUCT IMAGE IS REPRESENTATIVE PROVIDED BY THE MANUFACTURER. DO NOT MAKE BUYING DECISIONS SOLEY BASED ON THE IMAGE. PLEASE VERIFY SPECIFICATIONS MEET YOUR REQUIREMENTS.

High Flow, Unvalved, Hydraulic Quick Couplings - ST Series - BST-N6-BSPP

Name: High Flow, Unvalved, Hydraulic Quick Couplings - ST Series - BST-N6-BSPP
SKU: BST-N6-BSPP
Availability: OutOfStock

Parker's high flow quick couplers and nipples are unvalved for use where fluid lines require fast and easy connection and disconnection while providing maximum flow and low pressure drop.

Availability:

Backordered

SKU: BST-N6-BSPP

Qty:

Products specifications

Attribute name	Attribute value
Seal Material	na	Plating Type	na
Valve Type	Unvalved	Division	Quick Coupling Division
Maximum Operating Temperature	250.0 °F	Product Type	Push-to-Connect
Application	Hydraulic, high flow	Minimum Operating Temperature	-40.0 °F
Hex Size	1.38 inch	Flow Rate	28.0 Gal/min
Maximum Operating Pressure	1700	Coupling Half	Male Nipple
Connection Type	Female BSPP	Body Size (inch)	3/4
Body Material	BRASS

California Residents: Prop-65 Warning

Product resources

Literature and Reference Materials

Compliance, Certifications & Safety

Safety Guide: Quick Couplings and Related Accessories
