Brass 45° Flare Fittings - 2GF-10

All brass 45° flare fitting that resists mechanical pullout. Meets functional requirements of SAE J512 and J513.

Availability:	Backordered
Partner Available:	60 in stock

SKU: 2GF-10

$3.50

Products specifications

Attribute name	Attribute value
Division	Fluid System Connectors Division	Tube Material	Copper, Aluminum, brass, Welded Steel Hydraulic tubing that can be flared
Body Material	BRASS	Technology	Fluid & Gas Handling
O-Ring Material	Fluorocarbon	Maximum Operating Pressure	2800 psi
Nut Material	BRASS	Application	Pumps, Gas Grills, Coffee Makers, Adapters
Brand	Parker	Media	Water, Air, Inert and Non-combustible Gasses, Flammable Liquid, Freon
Division	Fluid System Connectors Division	Maximum Operating Temperature	250 °F
Minimum Operating Temperature	-53 °C	Specifications Met	SAE J512, SAE J513
Connection 2 Thread Size	NA	Connection 1 Thread Size	NA
Connection 2 Type	NA	Connection 3 Type	NA
Connection 1 Type	Flare	Connection 2 Tube Outside Diameter	NA
Connection 1 Tube Outside Diameter	5/8 inch	Connection 3 Tube Outside Diameter	NA
Connection 3 Thread Size	NA	Shape	Flare Gasket
Product Style	Flare
