Adaptor Plates - Series PADA - PADA1007-AA-BB

Name: Adaptor Plates - Series PADA - PADA1007-AA-BB
SKU: PADA1007-AA-BB
Availability: OutOfStock

Adaptor plates series PADA for NG10 to NG06 are used to combine cartridge components like covers and pilot valves in different sizes. They are available in two versions: connection A-B / B-A or connection A-A / B-B.

Availability:

Backordered

SKU: PADA1007-AA-BB

Qty:

Products specifications

Attribute name	Attribute value
Maximum Operating Temperature	60 °C	Body Material	Steel
Seal Material	n/a	Maximum Operating Pressure	350 bar
Minimum Operating Temperature	-25 °C	Mounting Type	Sandwich
Port Connection	NG10 - NG06, CETOP 05 - CETOP 03	Function	4-way
Division	Industrial Systems Division Europe	For Fluid Type	Hydraulic oil, Water glycol
Actuation Type	n/a	Product Series	Plate
Maximum Flow Rate	n/a
Adapter Type	A-A, B-B
