| Maximum Operating Pressure | 350 bar | Body Material | n/a |
| Minimum Operating Temperature | -37 °C | Maximum Kinematic Viscosity | 45-2000 SSU (6 to 420 cSt) |
| Division | Hydraulic Systems Division | Function | 3-Way |
| Maximum Inlet Pressure Rating | 350 bar | Seal Material | D-Ring (Standard) |
| Cavity Size | C10-3 | For Fluid Type | Mineral-based or synthetic hydraulic fluids |
| Actuation Type | Electrical, Manual | Operation Type | Solenoid operated, Manually operated |
| Valve Material | All parts steel. All operating parts hardened steel | Operating Temperature | -34 to +121 °C |
| Filter Efficiency Rating | ISO 4406 18/16/13, SAE Class 4 | Mounting Type | Screw in cartridge valve |
| Maximum Flow Rate | 4.5 Gal/min | Maximum Operating Temperature | +93 °C |
| Configuration | Normally Closed, Normally Open, Selector | Input Voltage | 85% of rated voltage at 72°F (20°C) min |
| Override Functionality | Push and Twist | Coil Nut Tightening Torque | 5-7 lb-ft |
| Flow Direction | 2-1 De-energized, 3-1 Energized | Coil Type | 5/8" Super Coil |
| Leak Rate | 160 @ 5000 PSI (350 BAR) cm3/min | Installation Torque | 51-55 lb-ft |
| Weight | 0.42 lb | Flow Rate | 15, 17 L/min |
| Response Time | 50-100 ms | | |
| Maximum Inlet Pressure Rating | 5000 PSI, 350 BAR | Seal Material | D-Ring (Standard) |
| Actuation Type | Electrical, Manual | Configuration | Normally Closed, Normally Open, Selector |
| Flow Direction | 2-1 De-energized, 3-1 Energized | Flow Rate | 4, 4.5 GAL/MIN, 15, 17 L/MIN |
