| Weight | 0.14 kg | Maximum Operating Pressure | 210 bar |
| Connection Size | n/a | Flow Rate | 60 L/min |
| Connection Type | n/a | Seal Material | Nitrile |
| Body Material | n/a | Maximum Kinematic Viscosity | 45-2000 SSU (6 to 420 cSt) |
| Division | Hydraulic Systems Division | Minimum Operating Temperature | -34 °C |
| Maximum Flow Rate | 60 L/min | Maximum Inlet Pressure Rating | 3000 psi |
| Installation Torque | 22 lb-ft | Coil Nut Tightening Torque | 4.1 Nm |
| For Fluid Type | Mineral-based or synthetic hydraulic fluids | Maximum Operating Temperature | +250 °F |
| Function | Proportional Flow Control/Regulator | Frequency | 100-400 Hz |
| Actuation Type | Electrical, Manual | Valve Material | All parts steel. All operating parts hardened steel |
| Operating Temperature | -34 to +121 °C | Filter Efficiency Rating | ISO 4406 18/16/13, SAE Class 4 |
| Coil Type | 5/8" Super Coil | Override Functionality | Infinite Control |
| Power Consumption | 18, 28 W | Current | 1.50 @ 12 VDC, 2.33 @ 12 VDC, 0.75 @ 24 VDC, 1.17 @ 24 VDC A |
| Leak Rate | 780 @ 3000 PSI (210 BAR) cm3/min | Hysteresis | 7% |
| Cavity Size | 4C | Configuration | Normally Closed, Pressure Compensated |
| Flow Direction | Inlet port 3, Bypass port 2, Regulated port 4 | Operation Type | Solenoid operated, Manually opertated |
| Flow Rate Accuracy | +/- 20% of Input Signal | Variation of Opening Point | 17% Nominal Amperage, 21% Nominal Amperage |
| Minimum Pressure Differential | 200, 300 psi | Maximum Regulated Flow Rate | 26, 30 L/min |
| Seal Material | Nitrile | Flow Rate | 16 GAL/MIN, 60 L/MIN |
| Actuation Type | Electrical, Manual | Configuration | Normally Closed, Pressure Compensated |
