| Connection Size | n/a | Connection Type | n/a |
| Maximum Operating Pressure | 3000 psi | Seal Material | Fluorocarbon |
| Body Material | n/a | Division | Hydraulic Cartridge Systems Division |
| Minimum Operating Temperature | -26 °C | Maximum Kinematic Viscosity | 45-2000 SSU (6 to 420 cSt) |
| Division | Hydraulic Systems Division | Weight | 0.13 kg |
| Override Functionality | n/a | Actuation Type | Electrical |
| Operation Type | Solenoid Operated | Installation Torque | 22 lb-ft |
| Coil Nut Tightening Torque | 4.1 Nm | For Fluid Type | Mineral-based or synthetic hydraulic fluids |
| Maximum Operating Temperature | +400 °F | Function | Proportional Flow Control/Regulator |
| Frequency | 100-400 Hz | Valve Material | All parts steel. All operating parts hardened steel |
| Operating Temperature | -15 to +400 °F | Filter Efficiency Rating | ISO 4406 18/16/13, SAE Class 4 |
| Variation of Closing Point | N/A | Maximum Inlet Pressure Rating | 210 bar |
| Wire Mesh Screen Included | Yes | Coil Type | 5/8" Super Coil |
| Cavity Size | 3X | Flow Direction | Top to Side (3 - 2) |
| Flow Rate | 30, 36 L/min | Maximum Flow Rate | 8, 9.5 Gal/min |
| Current | Max: 1.50 @ 12 VDC, 2.33 @ 12 VDC, 0.75 @ 24 VDC, 1.17 @ 24 VDC A | Power Consumption | 18, 28 W |
| Leak Rate | 780 @ 3000 PSI (210 BAR) cm3/min | Hysteresis | 7% |
| Configuration | Normally Closed, Pressure Compensated | Flow Rate Accuracy | +/- 7% |
| Variation of Opening Point | 25% of Input Signal | Minimum Pressure Differential | 13.8, 20.7 bar |
| Seal Material | Fluorocarbon | Actuation Type | Electrical |
| Flow Rate | 8, 9.5 GAL/MIN, 30, 36 L/MIN | Configuration | Normally Closed, Pressure Compensated |
