| Connection Size | n/a | Connection Type | n/a |
| Seal Material | Nitrile | Maximum Operating Pressure | 3000 psi |
| Body Material | n/a | Division | Hydraulic Cartridge Systems Division |
| Maximum Kinematic Viscosity | 45-2000 SSU (6 to 420 cSt) | Division | Hydraulic Systems Division |
| Minimum Operating Temperature | -30 °F | Power Consumption | 14 W |
| Weight | 0.17 lb | Override Functionality | n/a |
| Actuation Type | Electrical | Operation Type | Solenoid Operated |
| Coil Nut Tightening Torque | 3 lb-ft | Cavity Size | C08-3 |
| Flow Rate | 2 Gal/min | For Fluid Type | Mineral-based or synthetic hydraulic fluids |
| Maximum Operating Temperature | +250 °F | Function | Proportional Flow Control/Regulator |
| Frequency | 100-400 Hz | Valve Material | All parts steel. All operating parts hardened steel |
| Operating Temperature | -30 to +250 °F | Filter Efficiency Rating | ISO 4406 18/16/13, SAE Class 4 |
| Variation of Closing Point | N/A | Maximum Inlet Pressure Rating | 210 bar |
| Wire Mesh Screen Included | Yes | Coil Type | 1/2" Super Coil Low Watt (CCS) |
| Hysteresis | < 10% | Flow Direction | Top to Side (3 - 2) |
| Installation Torque | 27 Nm | Current | Max: 1.15 @ 12 VDC, 0.58 @ 24 VDC A |
| Leak Rate | 570 @ 3000 PSI (210 BAR) cm3/min | Configuration | Normally Closed, Pressure Compensated |
| Maximum Flow Rate | 2.0 Gal/min | Flow Rate Accuracy | +/- 7% |
| Variation of Opening Point | 25% of Input Signal | Minimum Pressure Differential | 10.3 bar |
| Seal Material | Nitrile | Actuation Type | Electrical |
| Flow Rate | 2 GAL/MIN, 7.5 L/MIN | Configuration | Normally Closed, Pressure Compensated |
